Pneumatic Type

The Pipe Cutting & Beveling Machine is a high-performance split frame system designed for precise pipe cutting, beveling, and end preparation across a wide range of pipe sizes and materials. Its split frame construction allows the machine to open and clamp around inline pipe, making it ideal for field operations where removing the pipe from the line is not possible.

The machine delivers cold cutting and simultaneous beveling, ensuring clean, accurate, and weld-ready results without producing heat, sparks, or flames. This cold-cutting technology eliminates heat affected zones and prevents distortion, making it exceptionally safe for use in flammable, pressurized, or hazardous environments.

Engineered for stability and accuracy, the equipment supports advanced machining operations such as single-point cutting, counterboring, and flange-facing, ensuring consistent performance on a variety of wall thicknesses and materials including carbon steel, alloy steel, stainless steel, and others.

Compact and easy to set up, the system requires minimal axial and radial clearance, allowing efficient operation even in tight or restricted areas. The machine is capable of handling pipe sizes from 1” to 48”, making it versatile for pipeline construction, industrial maintenance, shutdown work, and fabrication tasks.

Technical Specifications:

Working Range : 1-48 inch or 25-1230 mm.

Minimum Pipe Diameter : 94-1248 mm.

Maximum Outer Diameter : 147-1696 mm.

Working Weight : 35-236 kg.

Material : Steel.

Applications:

Oil & Gas pipelines for field repairs, line replacements and shutdown maintenance
Petrochemical and chemical plants for precise pipe cutting and beveling in process lines
Power generation plants for boiler tubes, steam lines and other high pressure piping
Offshore platforms and marine operations for safe cutting in enclosed or hazardous environments
Fabrication workshops for weld preparation and assembly of new pipe
Shutdown and turnaround operations requiring fast, accurate cutting under tight schedules

Key Features:

Machine splits quickly to mount around the outside diameter of in-line pipe.

Performs cutting and beveling at the same time, leaving a clean, precision weld-ready preparation.

Eliminates grinding and prevents heat-affected zones; improves safety with no flame, sparks, or material distortion.

Suitable for confined and tight workspaces.

Ensures consistent cutting performance on pipes of any wall thickness.

Works with carbon steel, alloy steel, stainless steel, and various other materials.

Available with Pneumatic, Electric, and Hydraulic drive systems.

Capable of machining pipe OD from 1" up to 48".

Product Specifications:

Technical Data

S. No.	Model Size	Working Range (OD) Inch	Working Range (OD) mm	d (mm)	D (mm)	L (mm)	Working Weight (kgs)
1	TCS 0103	1 – 3	25 – 89	94	147	159	35
2	TCS 0206	2 – 6	50 – 168	185	512	192	41.5
3	TCS 0308	3 – 8	80 – 230	236	564	192	42.5
4	TCS 0510	5 – 10	125 – 275	283	612	192	44.5
5	TCS 0612	6 – 12	168 – 325	334	665	192	53
6	TCS 0814	8 – 14	219 – 377	386	719	192	56
7	TCS 1016	10 – 16	273 – 426	438	776	195	60
8	TCS 1218	12 – 18	300 – 457	469	807	195	65.5
9	TCS 1420	14 – 20	355 – 508	519	862	195	77
10	TCS 1622	16 – 22	400 – 560	570	910	195	79
11	TCS 1824	18 – 24	457 – 610	618	960	195	85
12	TCS 2026	20 – 26	508 – 660	670	1020	195	96
13	TCS 2228	22 – 28	550 – 715	719	1084	198	114
14	TCS 2430	24 – 30	600 – 762	770	1134	198	116
15	TCS 2632	26 – 32	660 – 813	830	1194	207	120.5
16	TCS 3036	30 – 36	762 – 914	924	1296	214	144.5
17	TCS 3642	36 – 42	914 – 1066	1077	1468	216	197.5
18	TCS 4248	42 – 48	1066 – 1230	1248	1646	216	236
